Articulated Geared Runway Beam Trolley GBT3 RT
GBT3 RT
Overview
Incorporating Chain Wheel, Chain and Lifting Eye.
Designed and manufactured to negotiate a minimum of 1 metre beam radius. This Articulated Geared Runway Beam Trolley assures ease of application in use and low maintenance, incorporating two independent trolleys, a reinforced connecting plate with lifting eye.
The unit operates on four thrust bearings to minimize friction for trouble free use. As with all SUPERCLAMP products, the quality is of the highest standard to comply with user requirements.
WLL 10160kg (10 Ton). Weight 113.5kg. To fit fixed adjustment of 196mm Beam. Standard 3 metre (10ft) drop of chain. Longer lengths supplied on request.
Specifications
| MODEL | WLL Kg | Weight (Kg) | Beam Adjustment |
|---|---|---|---|
| GBT3 RT | 10160 (10 Ton) | 113.5 | Fixed 196mm |
Safe Use Guidelines
Read important safety information before use
